ราคา : ติดต่อสอบถาม฿ ติดต่อสอบถามราคา : 062-3288832 / 055-248998
หมวดหมู่ : Analog Mixers , อุปกรณ์เสริม , เสียง , Mixer ,
แบรนด์ : AZZA
Share
Rated Power : 600W
Mic Input : -60dB, 600Ω, unbalanced, 6.3mm TS port
Aux Input : -20dB, 10Ω, unbalanced, Stereo RCA port
Aux Output : 0dB, 600Ω, unbalanced, Stereo RCA port
Speaker Output : High Impedance: 100V; Low Impedance: 8Ω;
Volume Control for Each Zone : 6 zones speaker output with individual volume control; Note: the power capacity for each zone can reach the rated the power of amplifir. But make sure that the total power of zone 1~6 can not exceed the rated power.
Protection : AC fuse, overheating, overvoltage, overcurrent, short, DC, and muting during power on protections.
EQ for Master Output : Treble: ± 12dB at 10kHz; Bass: ± 12dB at 100Hz
Frequency Response : 20~20kHz (±3dB)
S/N : AUX input>80dB
T.H.D : <0.5% at 1kHz, at1/3 rated power.
Power Source : 220~240VAC, 50/60Hz
Power Consumption : 850W at rated power
Temperature / Humidity : -10°C ~ +40°C, <95%
Weight : 18kg
Dimensions : 482(W) x 88(H) x 350(D) mm
Shipping Weight : 20kg
Shipping Dimensions : 0.0382CBM, 58(W) x 47(H) x14(D) cm
